Product Overview
Our Sanitary Tri-Clamp Electric 2-Way Ball Valve is engineered to deliver reliable automated fluid control in high-purity systems. Fabricated from premium 304 or 316L stainless steel, this full-port automated valve features a non-retentive, polished flow path that complies with strict hygienic standards.
Equipped with versatile T-Type or L-Type configurations, it allows engineers to execute specialized fluid routing profiles. Combined with industry-standard Tri-Clamp ends and a resilient low-temperature rating down to -30°C, it provides seamless automation for dairies, breweries, pharmaceutical facilities, and cold-chain biochemical processes.
Technical Specifications
1. Valve Body Assembly
-
Material Options: Premium Grade 304 or 316L Stainless Steel
-
Connection Interface: Standard Tri-Clamp (Sanitary Quick-Release Ferrule)
-
2-Way Ball Valve Structure: T-Type / L-Type
-
Nominal Operating Pressure:$\le$ 1.0 MPa (10 Bar / 145 PSI)
-
Ambient Temperature Suitability: -30°C to +60°C (-22°F to +140°F), ideal for sub-zero processing environments.
2. Automated Electric Actuator
-
Compliance & Testing Standard: Manufactured to JB/T8219-1999 for industrial-process electric actuators.
-
Ingress Protection Rating:IP67 (Waterproof, dust-tight housing built to survive heavy clean-in-place washdowns).
-
Comprehensive Voltage Availability:
-
Alternating Current (AC): 24V / 110V / 220V / 380V
-
Direct Current (DC): 12V / 24V
-
-
Circuit Control Layouts: Configurable in Type A, B, C, D, E, F, G, and H wiring patterns to fit any localized automation setup.
Circuit Control Matrix (Types A to H)
| Control Architecture | Automation Profile | Feedback / Input Signals | Best Suited For |
| Type A / B / C | On/Off Control (Passive/Active contact) | Fully Open / Fully Closed position signals | General fluid isolation, switching paths, and simple multi-port routing. |
| Type D / E / F | Modulating Control (Proportional) | 4-20mA / 0-10V Input & Output | Precision fluid blending, proportioning, and dynamic flow tuning. |
| Type G / H | Intelligent / Bus System | Modbus RTU / Profibus / Local LCD Interface | Advanced smart factories and complex distributed DCS networks. |
Core Product Advantages
-
Flexible Flow Configurations: The internal T or L structure accommodates specific industrial process lines, optimizing your piping layout and minimizing system dead legs.
-
Extended Temperature Performance: Specially upgraded to withstand ambient environments as low as -30°C, making it safe for outdoor winter setups and specialized cryo-refrigeration loops.
-
Tool-Free Tri-Clamp Serviceability: Fastening clamp connectors ensure the entire unit can be separated from the processing lines in seconds for rapid seal checks or manual cleaning protocols.
-
Heavy-Washdown Safeguard: The rugged IP67 enclosure completely encapsulates the motor and gearing, providing reliable, continuous duty even during intensive daily cleanings.
Primary Industries & Applications
-
Beverage & Dairy Processing: Automated routing of raw milk, juices, beer wort, and clean water loops.
-
Pharmaceutical Batching: Multi-directional routing of purified ingredients, solvents, and media.
-
CIP / SIP System Automation: Directing acid, alkali, and clean water rinse streams during automated sanitation cycles.
-
Cold-Chain Chemicals: Fine chemical dosing and fluid distribution in low-temperature manufacturing environments.
